TVT America
TFP160Lb4
TFP160Lb4
Regular price
$3,002.03 USD
Regular price
$6,004.00 USD
Sale price
$3,002.03 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
| MT TFP Series High Performance 3phase AC Brake motor | |||
| IEC 160Lb 4pole 15Kw 230∆/400Y Volts/50hz, 480∆/820Y Volts 60Hz 1.2 Service factor | |||
| Ingress Protection 5 Dust, 4 Solids, Class F Insulation, S1 Continuous Duty | |||
|
PTC Thermistor thermal protectors in stator windings. 3ph AC brake Standard 230∆/400Y-Volts 50Hz, 277∆/480 Volts 60Hz. 24Vdc & 103Vdc brakes optional. |
|||
| Die-cast Aluminum Housing Polyester Epoxy Painted RAL 9006 White Aluminum for superior corrosion protection. | |||
| Pressed Steel brake Cover Polyester Epoxy Painted RAL 5010 TVT Blue. | |||
| Double Terminal Box, rotatable at 90º intervals, for convenient wiring and Protection IP56 | |||
| UL/CSA/CE listed, ATEX Ex 2-22 3G/3D certified. | |||
| "Made in Italy… Loved in America"® |
